Standard Configuration:

A. Comprehensive Technical & Functional Description

1. Chair Structure & Movement:

   • Base: A stable, often slim-profile foundation housing the motor, hydraulic pump (if hydraulic), and electronics. It may feature a 360-degree swivel for easy positioning.

   • Actuation System: Modern chairs primarily use quiet, electric motors for smooth, programmable movement. Some models may use hydraulic systems. The chair articulates at key points (backrest, seat, leg rest) to achieve various positions.

   • Positions: Key programmable positions include:

     • Upright: For patient entry/exit and consultation.

     • Treatment/Reclined: The standard working position, where the patient is supine and the oral cavity is easily accessible.

     • Trendelenburg: A position where the feet are slightly above the head, useful for certain procedures or patient comfort.

2. Upholstery & Hygiene:

   • Material: High-grade, medical-grade vinyl or synthetic leather that is non-porous, anti-bacterial, and easy to clean and disinfect. Seamless designs are preferred to prevent fluid ingress.

   • Cushioning: High-density foam with varying firmness in different zones (e.g., lumbar support) for prolonged patient comfort.

3. Integrated Systems & Technology:

   • Control System: Can be a touchscreen panel, wired remote, or wireless handheld remote, often with programmable memory buttons for instant recall of preferred settings for different dentists or procedures.

   • Dental Delivery System: The chair is the anchor for the dental unit, which includes the tray/arm holding handpieces (drills), ultrasonic scaler, air-water syringe (tri-function syringe), and suction devices. This can be chair-mounted (follows chair movement) or ceiling-mounted.

   • Accessory Integration:

     • Cuspidor/Spittoon: A built-in or retractable bowl with a suction system for rinsing.

     • Assistant's Instrument Tray: A movable side tray for additional instruments.

     • Lighting: An integrated articulating LED examination light with shadow-reduction technology, often controlled from the same panel.

4. Ergonomics & Patient Comfort:

   • Adaptable Contours: The chair conforms to the patient's body to reduce pressure points.

   • Adjustable Headrest: Pivots and slides to perfectly support the head and neck in any position.

   • Armrests: Often foldable or retractable for easy patient access and to provide support during treatment.

Standard Configuration:

1.24V DC motor

2.Adjustable protective headrest

3.Electric dental chair control system

4.Three way syringe

5.Imported solenoid valve

6.Weak,Strong suction saliva dispenser

7.Import steam pipe

8.LED viewing light

9.Water purification filter

10Large injection molding tool tray

11.Mouthwash heating system

12.Master control system

13.Assistant operation control system

14.Multifunctional foot pedal

15.One click spitting position

16.Nine memory seats

17.Ceramic spittoon

18.High quality environmentally friendly leather

19.Balance arm belt air brake device

20.Six bead LED (oral light with three color adjustable light sensitivity)

21.Water supply quantitative water supply setting system

22.Dentist stool

Optional Items:

1. High & low speed handpiece

2. Curing light

3. Scaler

4. Micro motor

5. Intra oral camera

6.X-ray with sensor

7.Suction motor
